RFID Disc Tag, RFID Disk Tag, RFID Coin Tag

RFIDDisc tag are finely laminated with PVC or POLY. For Clear Disc Tag, itis transparent, you can see the COB and antenna directly. PVC Disc Tagare more steady under high temperature compared with Clear Disc Tag.

RFIDDisc Tag(EM4102, Mifare 1K, UHF) is available with 3M sticker,holepunch anti-metal layer to mount on metal. Various sizes andcustomization logo.

Applications for the Disc tag:
- Process Control & Factory Automation
- Item Identification
- Security

Key Features:
- Dimensions: dia CDT 14/CDT 15/CDT 17/CDT 18/CDT 20/CDT 22/CDT 25/CDT 30/CDT 40/CDT 50mm
- type: CDT14/CDT15/CDT17/CDT18/CDT20/CDT22/CDT25/CDT30/CDT40/CDT50
- Thickness Option: 1.0mm or 1.5mm
- Housing: PVC, lamination
- Water-proof: Yes, IP67
- Operating Temperature: -20 to +60°C
- Stockage Temperature: -20 to +65°C
- PET material upon extensive requirement on temperature.

Optional RFID ICs:
- 125KHZ: EM4100, EM4102, GK4001, EM4550, T5577, Hitag 1, Hitag 2, Hitag S
- 13.56mhz: Mifare 1K, Fudan F08, Mifare 4K, Mifare utralight, Mifare DESfire 4K, Legic 256, I CODE SLI, Titag it HF1
- UHF: EPC Class 1 GEN 2

Customization Support:
- Self-adhesive layer(3M or normal)
- Anti-metal layer
- Silk-Screen Printing LOGO
- Laser Engrave LOGO
- Jet Printing Serial Number
- Laser Engrave Serial Number
- Hole Punch

Our certification: IC CARD REGISTER CERTIFICATION, ISO9001 CERTIFICATION, ROHS.

Vision and Objective: Providing you with excellent quality
Decreasing your cost at our best
Support you with fast shipment and good service
Help you to develop new products

Passivetags(proximity tag) are those energized by the reader itsef. The RFIDtags contain no power source, but have very long lifetimes (nearindefinite) typically. Compared with active tags, a drawback of passivetag is the read range, which can typically reach 2cm (1in) to 1.5m (4.5ft); but a strong positive is the individual tag cost of a passive tag.
Inan RFID system, the transponder which contains the data to betransmitted is called an RF tag. Passive RF tags obtain operating powergenerated from the RF reader. This kind of tag are smaller and lighterthan active tags but have a shorter communication range and require ahigh powered reader. Passive tags are generally read-only and as such,once it is programmed with data, that data cannot be modified.
